Combo Overview:

The Hobbywing EZRun MAX6 G2 ESC is built with the most rugged and high-quality components, featuring cutting-edge firmware for unmatched power and performance, making it ideal for hardcore bashing applications. This ESC is designed to handle extreme power demands while offering responsive protection against damage due to overloading, overuse, or human error.

With remarkable acceleration capabilities and stable output, the MAX6 can deliver instant full-torque start-ups, high-speed racing on straightaways, and the ability to power through rough terrain. Users have the flexibility to adjust ESC parameters to suit their preferences and skills.

The ESC boasts an innovative all-weather conditions waterproof sensor interface design, enhancing its overall waterproof and dustproof performance. It includes a built-in ultra-powerful switch mode BEC with a continuous current of 8A, instant 25A, and support for 6V/7.4V/8.4V. The MAX6 also supports turbo timing settings and offers multiple protection functions including an intelligent automatic fan start-stop function.

Additional features of this ESC include high voltage built-in BEC, a graph data logging function that allows users to view various running data on the HW LINK app, an advanced and secure electronic switch, and a built-in anti-spark system for added safety. The Hobbywing EZRun MAX6 G2 ESC is designed for 1/6 and 1/7 scale touring cars, buggies, truggies, and trucks, making it a versatile and powerful choice!

Features:

• ESC
• Built with the most rugged and high-quality components
• Unmatched power and performance for racing applications
• Responsive protection against overloading and damage
• Incredible acceleration and stable output
• Innovative all-weather conditions waterproof sensor interface
• Ultra-powerful switch mode BEC with 8A continuous current
• Supports turbo timing settings
• Multiple protection functions including an intelligent automatic fan start-stop function
• Data logging function for monitoring running data
• Built-in wireless module
• Motor
• IP-67 Water and elements proof design
• 4-Pole rotor design for more torque with strong explosive force
• Sensored interface
• Precision CNC-machined shell

Specifications:

• ESC:
  • Type: Sensored Brushless
  • Application: 1/5 & 1/6 lightweight Scale Touring Car, Buggy, Truggy, and Truck
  • Input Voltage: 3-8S LiPo Battery
  • Continuous Current: 200A
  • Peak Current: 1200A
  • BEC Output: Switchable (6.0V-8.4V)
  • Length: 70mm
  • Width: 56mm
  • Height: 45.5mm
  • Weight: 245g
  • Motor Limit: (6S) 2400kV - (8S) 1700kV
• Motor:
  • kV Rating: 1250kV
  • Type: Sensored Brushless
  • Applications: Lightweight 1/7 & 1/8 Scale Touring Cars, Buggies, Truggies, and Trucks
  • Input Voltage: 3-8S LiPo
  • No Load Current: 6.6A
  • Poles: 4
  • Diameter/Length: 56mm (2.20") / 90.2mm (3.55")
  • Shaft Diameter/Length: 8mm (0.31") / 30mm (1.18")
  • Front Bearing: 22x8x7mm
  • Rear Bearing: 19x8x6mm
  • Weight: 867g

Includes:

• (1) EzRun MAX6 G2 ESC
• (1) EzRun 5690 SD Brushless Motor (1250kV)
• (1) Hobbywing decal sheet
• User's manual

Electric Motor and ESC Combo:

The Hobbywing EZRun Max8 G2S Brushless ESC and 4268SD G2R Brushless Motor Combo are engineered to deliver peak performance in 1/8 scale applications. This heavy hitting combo features the optimized G2R Brushless Motor, which offers maximum torque and increased power with lower internal resistance, ensures efficient and cooler operation. This combo is designed to maximize your potential with unmatched performance and reliability.

About the Combo

Technology

The OTA programmer allows for real-time data recording, enabling you to monitor throttle, voltage, current, temperature, motor RPM, and more. This data can be viewed in real time and recorded using HW Link for easy data analysis. The system includes multiple protections such as low-voltage cutoff, ESC and motor thermal protection, fail-safe (throttle signal loss protection), and reverse polarity protection. Firmware upgrades are possible via the Hobbywing multifunction LCD Pro program box or the OTA programmer (both sold separately).

Motor

The Hobbywing EZRun 4268SD G2R Sensored Brushless Motor has been designed to provide maximum speed and power. Using an advanced sensored system, this motor can deliver more aggressive launches, higher speeds and better efficiencies. With the waterproof sensor connection, you can enjoy all the benefits of a sensored system no matter the terrain.

ESC

The ESC features three built-in 680uF capacitors, enhancing performance by 74% (870uF) compared to the MAX8 ESC. These large capacitors eliminate the need for external capacitors on your vehicle. It also includes a patented frameless fan design, which rapidly transfers internal heat to the integrated housing radiator. High airflow from the fan's side and a copper thermal conduction sink on the internal power plate ensure efficient cooling. This design maintains the ESC's reliability and optimal thermal condition.

Features

• Motor
• Advanced sensored brushless technology ensures precise control and smooth power delivery
• The fully closed case design effectively keeps dust and debris out, protecting the internal components
• The waterproof sensored motor is built to withstand wet conditions, allowing for reliable operation in most environments
• Designed for extreme speed and power, this motor is engineered to deliver exceptional acceleration and top-end speed
• ESC
• Enhanced waterproof and dust-proof design for various climates.
• Built-in 6A/15A switch mode BEC, supports 6V/7.4V/8.4V servos.
• Advanced electronic switches prevent dust, humidity, and impact issues.
• 32-degree turbo timing increases RPM by 25% with compatible motors.
• Real-time data logging and firmware updates via HW LINK app and Bluetooth.
